Table and cell styling tools
CKEditor 5 comes with some additional tools that help you modify the look of tables and table cells. You can control border color and style, background color, padding, or text alignment.
# Demo
Put the caret anywhere inside the table to open the table toolbar. Click the table properties button
in the toolbar. A pop–up will open with options to shape the look of the entire table. On the other hand, the cell properties button gives you access to styling options for individual table cells.Learn more about configuring color palettes in the table styling pop–up interfaces.
The planet of robots
Humans have always searched for new places to explore and new ways to get where they wanted. Where no human could go, they would send robots to do the job for them. Mars, one of Earth's closest neighbors, is currently home to quite a few robotic devices. Those able to move around roam the planet's red sands while relaying their experience back to their mother planet.
Color coding for missions | |||
Failed | Successful | In progress | Planned |
Country/Agency | Rover | Date of landing | Operational time | Distance traveled | Notes |
---|---|---|---|---|---|
![]() |
PROP-M rover | November 27, 1971 | 0 days | 0 km | Lost when it crash-landed on Mars |
![]() |
PROP-M rover | December 2, 1971 | 0 days | 0 km | Lost when Mars 3 lander stopped communicating about 20 seconds after landing |
![]() |
Sojourner | July 4, 1997 | 85 days | 100 m (330 ft) | First successful rover on Mars |
![]() |
Spirit | January 4, 2004 | 2269 days | 7.73 km (4.80 mi) | |
![]() |
Opportunity | January 25, 2004 | 5498 days | 45.16 km (28.06 mi) | The longest distance traveled by any rover and the most days operated |
![]() |
Curiosity | January 25, 2012 | 3214 days |
24.85 km (15.44 mi) as of 4 March 2021 |
Currently active |
![]() |
Perseverance | February 18, 2021 | 96 days |
322 m (1,056 ft) as of 14 May 2021 |
Currently active |
![]() |
Zhurong | May 14, 2021 | 11 days | Currently active | |
![]() |
Rosalind Franklin | 2029 (planned) | 420 days (planned) | Planned to launch in 2028 |
This demo only presents a limited set of features. Visit the full-featured editor example to see more in action.
# Installation
By default, table styling tools are not included in the predefined builds and must be installed separately.
To enable the rich table and cell styling tools in your editor, you need to have the @ckeditor/ckeditor5-table
package installed (it is already present in the predefined builds):
npm install --save @ckeditor/ckeditor5-table
Then add the Table
, TableToolbar
, TableProperties
, and TableCellProperties
plugins to your plugin list and configure the table toolbar:
import Table from '@ckeditor/ckeditor5-table/src/table';
import TableToolbar from '@ckeditor/ckeditor5-table/src/tabletoolbar';
import TableProperties from '@ckeditor/ckeditor5-table/src/tableproperties';
import TableCellProperties from '@ckeditor/ckeditor5-table/src/tablecellproperties';
ClassicEditor
.create( document.querySelector( '#editor' ), {
plugins: [ Table, TableToolbar, TableProperties, TableCellProperties, Bold, /* ... */ ],
toolbar: [ 'insertTable', /* ... */ ],
table: {
contentToolbar: [
'tableColumn', 'tableRow', 'mergeTableCells',
'tableProperties', 'tableCellProperties'
],
tableProperties: {
// Configuration of the TableProperties plugin.
// ...
},
tableCellProperties: {
// Configuration of the TableCellProperties plugin.
// ...
}
}
} )
.then( /* ... */ )
.catch( /* ... */ );
Read more about installing plugins.
# Configuring styling tools
Table and cell styling tools let you create tables with colorful backgrounds and borders. These colors can be easily picked using color palettes in the table properties
and cell properties pop-ups. To help users choose the right colors for the content, you can pre-configure such color palettes, like in the editor below:A beautiful color palette
Red | Pink | Purple | Deep Purple |
Indigo | Blue | Light Blue | Cyan |
Teal | Green | Light Green | Lime |
Yellow | Amber | Orange | Deep Orange |
Brown | Gray | Blue Gray | White |
With the selection inside any table cell, use the table properties
and cell properties buttons in the toolbar to check available styling and color options.# Customizing color palettes
You can use these specific configuration options to define customized color palettes for background and border colors to match your document:
tableProperties.borderColors
– Defines the color palette for table borders.tableProperties.backgroundColors
– Defines the color palette for table background.tableCellProperties.borderColors
– Defines the color palette for cell borders.tableCellProperties.backgroundColors
– Defines the color palette for cell background.
The above configurations do not impact the data loaded into the editor, i.e. they do not limit or filter the colors in the data. They are used only in the user interface allowing users to pick colors in a more convenient way.
For instance, to define the same color palette for all border and background configurations, use the following code snippet:
const customColorPalette = [
{
color: 'hsl(4, 90%, 58%)',
label: 'Red'
},
{
color: 'hsl(340, 82%, 52%)',
label: 'Pink'
},
{
color: 'hsl(291, 64%, 42%)',
label: 'Purple'
},
{
color: 'hsl(262, 52%, 47%)',
label: 'Deep Purple'
},
{
color: 'hsl(231, 48%, 48%)',
label: 'Indigo'
},
{
color: 'hsl(207, 90%, 54%)',
label: 'Blue'
},
// More colors.
// ...
];
ClassicEditor
.create( document.querySelector( '#editor' ), {
plugins: [ Table, TableToolbar, TableProperties, TableCellProperties, Bold, /* ... */ ],
toolbar: [ 'insertTable', /* ... */ ],
table: {
contentToolbar: [
'tableColumn', 'tableRow', 'mergeTableCells',
'tableProperties', 'tableCellProperties'
],
// Set the palettes for tables.
tableProperties: {
borderColors: customColorPalette,
backgroundColors: customColorPalette
},
// Set the palettes for table cells.
tableCellProperties: {
borderColors: customColorPalette,
backgroundColors: customColorPalette
}
}
} )
.then( /* ... */ )
.catch( /* ... */ );
# Default table and table cell styles
The table styles feature allows for configuring the default look of the tables in the editor. The configuration object should be synchronized with the editor content styles.
The “Table properties” and “Table cell properties” buttons in the toolbar will show the table and table cell properties applied to the table or table cells.
The stylesheet for the editor displayed below looks as follows:
.ck-content .table {
float: left;
width: 550px;
height: 450px;
}
.ck-content .table table {
border-style: dashed;
border-color: 'hsl(90, 75%, 60%)';
border-width: 3px;
}
.ck-content .table table td {
text-align: center;
vertical-align: bottom;
padding: 10px
}
The same values must be passed to the editor configuration as:
- The
table.tableProperties.defaultProperties
object for the table properties. - The
table.tableCellProperties.defaultProperties
object for the table cell properties.
const tableConfig = {
table: {
tableProperties: {
// The default styles for tables in the editor.
// They should be synchronized with the content styles.
defaultProperties: {
borderStyle: 'dashed',
borderColor: 'hsl(90, 75%, 60%)',
borderWidth: '3px',
alignment: 'left',
width: '550px',
height: '450px'
},
// The default styles for table cells in the editor.
// They should be synchronized with the content styles.
tableCellProperties: {
defaultProperties: {
horizontalAlignment: 'center',
verticalAlignment: 'bottom',
padding: '10px'
}
}
}
}
};
The table element should be aligned to the left
side by default. Its size should be 550x450px
. The border style should be dashed
, 3px
of its width, and the color specified as Light green
.
The content should be away about 10px
from the cell’s edges (padding
), vertically aligned to bottom
and horizontally to center
.
The same will be applied to new tables and cells if they are inserted into the editor.
Fuzzy space travelers
Before people could leave the cradle of humanity and enter the cosmic void, tests were required. Many animals risked and sometimes lost their lives to pave the way to the stars for humankind.
Animal spaceflight started in the late 1940s. The initial launches used German A4 rockets, but later on each country developed its own carriers. Simian, canine, and rodent space farers were the most important test subjects during the first stage of the space race, before launching human astronauts. However, animal spaceflight is very much a thing even today. In 2018, a rodent crew arrived at the International Space Station!
Animal astronauts by country of origin | |
American: Fruit flies; primates first flew in the 1940s. The most memorable was Ham, a chimpanzee. |
Soviet: Mostly dogs, sent to space since the 1950s. The most memorable was Laika, who died during the first part of the journey. |
French: Rats and cats (1960s). Félicette was the most notable one and the only French cat that survived the landing. |
Chinese: Mice, rats, and dogs (1960s). |
Read more about all supported properties for the table and table cell features in their API documentation.
The default table and table cell styles do impact the data loaded into the editor. Default properties will not be kept in the editor model.
# Common API
# UI components
The TableProperties
and TableCellProperties
plugins register the following UI components:
Component name | Registered by |
---|---|
The 'tableProperties' button |
TableProperties |
The 'tableCellProperties' button |
TableCellProperties |
# Toolbars
The TableProperties
and TableCellProperties
plugins allow adding the tableProperties
and tableCellProperties
items to the toolbar. It is possible to configure its content.
# Editor commands
Command name | Command class | Belongs to (top–level plugin) |
---|---|---|
'tableBorderColor' |
TableBorderColorCommand |
TableProperties |
'tableBorderStyle' |
TableBorderStyleCommand |
|
'tableBorderWidth' |
TableBorderWidthCommand |
|
'tableAlignment' |
TableAlignmentCommand |
|
'tableWidth' |
TableWidthCommand |
|
'tableHeight' |
TableHeightCommand |
|
'tableBackgroundColor' |
TableBackgroundColorCommand |
|
'tableCellBorderStyle' |
TableCellBorderStyleCommand |
TableCellProperties |
'tableCellBorderColor' |
TableCellBorderColorCommand |
|
'tableCellBorderWidth' |
TableCellBorderWidthCommand |
|
'tableCellHorizontalAlignment' |
TableCellHorizontalAlignmentCommand |
|
'tableCellWidth' |
TableCellWidthCommand |
|
'tableCellHeight' |
TableCellHeightCommand |
|
'tableCellPadding' |
TableCellPaddingCommand |
|
'tableCellBackgroundColor' |
TableCellBackgroundColorCommand |
|
'tableCellVerticalAlignment' |
TableCellVerticalAlignmentCommand |
We recommend using the official CKEditor 5 inspector for development and debugging. It will give you tons of useful information about the state of the editor such as internal data structures, selection, commands, and many more.
# Contribute
The source code of the feature is available on GitHub at https://github.com/ckeditor/ckeditor5/tree/master/packages/ckeditor5-table.
Every day, we work hard to keep our documentation complete. Have you spotted outdated information? Is something missing? Please report it via our issue tracker.
